(To fix this product at your doorstep, contact our below listed Service Centre)

Specifications:

• Platform: AMD

• Socket: AM5

• CPU Type: Ryzen 9000, Ryzen 8000, Ryzen 7000

• Chipset: A620

• Memory Speed: Up to 7200+

• Max Memory Support: 128 GB

• Supported Memory Type: DDR5

• Channel Supported: Dual Channel

• Memory Feature: Supports DDR5 ECC/non-ECC, un-buffered memory; Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules

• Graphics Port: 1 x HDMI, 1 x DisplayPort

Expansion Slots:

• CPU:

  • 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode

• Chipset:

  • 2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)

  • 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module

  • 15μ Gold Contact in VGA PCIe Slot (PCIE1)

Back Panel I/O Ports:

• 2 x Antenna Mounting Points

• 1 x HDMI Port

• 1 x DisplayPort 1.4

• 1 x USB 3.2 Gen1 Type-C Port

• 3 x USB 3.2 Gen1 Type-A Ports

• 2 x USB 2.0 Ports

• 1 x RJ-45 LAN Port

• 1 x BIOS Flashback Button

• HD Audio Jacks: Line in / Front Speaker / Microphone

Internal I/O Connectors:

• 1 x SPI TPM Header

• 1 x Power LED and Speaker Header

• 1 x CPU Fan Connector (4-pin)

• 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x Front Panel Audio Connector

• 2 x USB 2.0 Headers (Supports 4 USB 2.0 ports)

• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)

• Form Factor: Micro-ATX

(Note: Product Image is indicative purpose only)
