Specifications:

• Platform : INTEL

• Socket : LGA1700

• CPU Type : 14th Gen, 13th Gen, 12th Gen, Pentium Gold, Celeron Processors

• Chipset : B760

• Memory Speed : up to 4800

• Max Memory Support : 128 GB

• Supported Memory Type : DDR4

• Channel Supported : Dual Channel

• Memory Feature :
  • Supports Dual-Channel mode
  • Supports non-ECC, un-buffered memory
  • Supports Intel Extreme Memory Profile (XMP)

• Graphics Port : 1x HDMI, 1x DisplayPort, 1x VGA

• Expansion Slots :
  • 1x PCI-E x16 slot
  • 2x PCI-E x1 slot
  • PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
  • PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset)
  • PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset)

• Back Panel I/O Ports :
  • VGA
  • DisplayPort
  • HDMI
  • Keyboard / Mouse
  • USB 2.0
  • LAN port
  • Audio Connectors
  • USB 3.2 Gen 1 5Gbps (Type-A)
  • USB 3.2 Gen 2 10Gbps (Type-C)

• Internal I/O Connector :
  • 1x Power Connector (ATX_PWR)
  • 1x Power Connector (CPU_PWR)
  • 1x CPU Fan
  • 2x System Fan
  • 2x Front Panel (JFP)
  • 1x Chassis Intrusion (JCI)
  • 1x Front Audio (JAUD)
  • 1x Printer Port (JLPT)
  • 1x Com Port (JCOM)
  • 1x RGB LED connector (JRGB)
  • 1x TPM pin header (Support TPM 2.0)
  • 4x USB 2.0 ports
  • 2x USB 5Gbps Type A ports

• Form Factor : Micro-ATX
