Specification

• Video Resolution: 5MP (2880 × 1620) @ up to 25 FPS CP PLUS+2CP PLUS+2

• Image Sensor: 5MP PS CMOS CP PLUS+3CP PLUS+3VGTECH INFOTEL+3

• Lens: Fixed 3.6 mm (optional 2.8 mm) CP PLUS+2CP PLUS+2

• Minimum Illumination: 0.02 lux (Color, 30 IRE); 0.002 lux (B/W, 30 IRE); 0 lux (IR on) CP PLUS+2CP PLUS+2

• Day / Night / Dual Light:
   • Auto ICR / Color / B&W modes CP PLUS+2VGTECH INFOTEL+2
   • Dual-light (IR + warm LED) CP PLUS+2VGTECH INFOTEL+2
   • IR Range: up to 30 m CP PLUS+2CP PLUS+2
   • Warm Light Range: ~ 20 m CP PLUS+1

• Signal Formats / Output: Switchable between CVI / TVI / AHD / CVBS via one BNC port CP PLUS+1

• Features: DWDR, 2D DNR, BLC, HLC, Privacy Mask (4 areas), Mirror function CP PLUS+1

• S/N Ratio: > 55 dB CP PLUS+1

• Pan / Tilt / Rotation Range: Pan 0°–360°, Tilt 0°–78°, Rotation 0°–360° CP PLUS

• Operating Temperature: –40 °C to +55 °C CP PLUS+1

• Humidity: < 95% RH, non-condensing CP PLUS+1

• Power Supply: 12 V DC ± 30% CP PLUS+2CP PLUS+2

• Power Consumption: Max ~ 2.6 W (when warm LED active) CP PLUS+2VGTECH INFOTEL+2

Dimensions & Weight

• Dimensions: 85 mm × 77.1 mm (diameter × height) CP PLUS+2CP PLUS+2

• Weight: ~ 0.11 kg CP PLUS+1

Usage

Suitable for both indoor and outdoor surveillance, especially where dual-light (IR + warm LED) helps in low light / night scenarios.
Works well in homes, small offices, shops, entrances, corridors, etc.

(Note)

Product image is for indicative purpose only.
